IRF6644
Absolute Maximum Ratings
Parameter
Max.
Units
P D @T A = 25°C
P D @T A = 70°C
P D @T C = 25°C
T P
T J
T STG
Power Dissipation
Power Dissipation
Power Dissipation
Peak Soldering Temperature
Operating Junction and
Storage Temperature Range
2.8
1.8
89
270
-40 to + 150
W
°C
Thermal Resistance
Parameter
Typ.
Max.
Units
R θ JA
R θ JA
Junction-to-Ambient
Junction-to-Ambient
–––
12.5
45
–––
R θ JA
R θ JC
R θ J-PCB
Junction-to-Ambient
Junction-to-Case
Junction-to-PCB Mounted
20
–––
1.0
–––
1.4
–––
°C/W
100
D = 0.50
10
1
0.20
0.10
0.05
0.02
0.01
τ 4
τ C
0.1
0.01
τ J
τ J
τ 1
τ 1
R 1
R 1
τ 2
R 2
R 2
τ 2
R 3
R 3
τ 3
τ 3
R 4
R 4
τ 4
τ
Ri (°C/W)
0.6784
17.299
17.566
τ i (sec)
0.00086
0.57756
8.94
0.001
SINGLE PULSE
( THERMAL RESPONSE )
Ci= τ i / Ri
Ci i / Ri
9.4701 106
Notes:
1. Duty Factor D = t1/t2
2. Peak Tj = P dm x Zthja + Tc
0.0001
1E-006
1E-005
0.0001
0.001
0.01
0.1
1
10
100
t1 , Rectangular Pulse Duration (sec)
Fig 3. Maximum Effective Transient Thermal Impedance, Junction-to-Ambient ?
Notes:
? Surface mounted on 1 in. square Cu board, steady state. ? T C measured with thermocouple incontact with top (Drain) of part.
? Used double sided cooling , mounting pad. ? R θ is measured at T J of approximately 90°C.
? Mounted on minimum footprint full size board with metalized
back and with small clip heatsink.
? Surface mounted on 1 in. square Cu
board (still air).
www.irf.com
? Mounted to a PCB with
small clip heatsink (still air)
? Mounted on minimum
footprint full size board with
metalized back and with small
clip heatsink (still air)
3
